Description

* Patented "Analysis Expert" as part of embedded intelligence, enables even a novice user to conduct sophisticated analysis

* New COLOR screen that is 4-8 times larger than opposition products, offering even easier viewing of data in all conditions

* Built-in 32MB internal memory, upgradeable to Giga-Bytes size using off-the-shelf Flash RAM cards

* Ability to display up to four plots at once

* Fast USB and Ethernet communications, in addition to conventional serial port

* User friendly soft function keys

* Environmental protection to IP65, giving a durable, waterproof and dust-tight analyzer

* Package modularity enable the system to be a upgraded gradually whenever required

Features

* Portable route-based vibration data collector and extendable for advanced analysis such as: Advance Cross Channels, ODS/Modal Analysis, Transient Analysis, and Impact Test

* Expandable system to Laser Alignment, Balancing, and Motor Analysis

* Variable speed analysis for mor accurate evaluation of developing problem

* Advanced bearing analysis using "PeakVue" and Demodulation trchnology, allowing early and accurate bearing fault diagnosis

* Patented Slow Speed Technology (SST)

* Accept ICP sensor and other type of generic AC or DC voltage signal from vibration, microphone, temperature, electric current, voltage, pressure sensors, etc

Product Options:

A2130A1
CSI 2130 Machinery Health Analyzer Single Channel

A2130A2
CSI 2130 Machinery Health Analyzer Dual Channel

A2130D1
CSI 2130 Machinery Health Data Collector

A21301Q
CSI 2130 Machinery Health Analyzer Single Channel, Safety Rated

A21302Q
CSI 2130 Machinery Health Analyzer Dual Channel, Safety Rated

A2130D1Q
CSI 2130 Machinery Health Data Collector, Safety Rated

A8130Z1
CSI 2130 Machinery Health Analyzer Single Channel (non-route)

A8130Z2
CSI 2130 Machinery Health Analyzer Dual Channel (non-route)
